Diamond dry cutting saw blades - hot-press sintered, wide turbo rim segments with protective teeth

item No : DCHS-14
Diameter: 105-230mm
Bore: 20/22.23mm
Segment height: 8mm
Segment type: wide turbo rim with protective teeth
Production process: hot-press sintered

Inquiry Now

Detailed Description

Inquiry Now

Diamond dry cutting saw blades - hot-press sintered, wide turbo rim segments with protective teeth

Hot press sintered diamond saw blades with wide turbo rim segments and outspread protective teeth for fast dry cutting various hard, medium, soft stone such as granite, marble, sandstone, limestone, etc. without water or with less water.

Also we can make the segments bond for general cutting of other materials such as concrete, asphalt, ceramic, bricks, etc..

Dry or wet use, water coolant is benefit for longer cutting life.

Usually used on: angle grinders, table saws, handheld saw machines.

Bore size: 15.88mm(5/8"), 20.00mm, 22.23mm(7/8") or as per demand.

Production process: hot-press sintered.

Code No.	Diameter	Segment size (W*H)mm	Protective Teeth No.
DCHS-14-105	105mm(4")	2.4*8mm	3
DCHS-14-115	115mm(4.5")	2.4*8mm	3
DCHS-14-125	125mm(5")	2.4*8mm	3
DCHS-14-150	150mm(6")	2.6*8mm	4
DCHS-14-180	180mm(7")	2.6*8mm	4
DCHS-14-200	200mm(8")	2.8*8mm	x
DCHS-14-230	230mm(9")	3.0*8mm	5

The above specifications & photos are for reference, other specification may be available as per demand.
