Diamond dry cutting saw blades - narrow turbo continuous rim segments

item No : DCHS-010
Diameter: 105-230mm
Bore: 20/22.23mm
Segment height: 8/10mm
Segment type: narrow turbo continuous rim
Production process: hot-press sintered

Inquiry Now

Detailed Description

Inquiry Now

Diamond dry cutting saw blades - hot-press sintered, narrow turbo continuous rim segments

Hot press sintered diamond saw blades with narrow turbo continuous rim segments for fast dry cutting various hard, medium, soft stone such as granite, marble, sandstone, limestone, etc. without water or with less water.

Also we can make the segments bond for general cutting of other materials such as concrete, asphalt, ceramic, bricks, etc..

Dry or wet use, water coolant is benefit for longer cutting life.

Usually used on: angle grinders, table saws, handheld saw machines.

Bore size: 15.88mm(5/8"), 20.00mm, 22.23mm(7/8") or as per demand.

Production process: hot-press sintered.

Code No.	Diameter	Segment Thickness	Segment Height
DCHS-010-105	105mm(4")	1.2/1.4/1.8/2.4mm	8mm/10
DCHS-010-110	110mm(4.25")	1.4/1.8/2.0mm	8/10mm
DCHS-010-115	115mm(4.5")	2.4mm	10mm
DCHS-010-125	125mm(5")	2.4mm	8/10mm
DCHS-010-150	150mm(6")	2.6mm	8/10mm
DCHS-010-180	180mm(7")	2.8mm	8/10mm
DCHS-010-200	200mm(8")	2.8mm	10mm
DCHS-010-230	230mm(9")	3.0mm	10mm

The above specifications & photos are for reference, other specification may be available as per demand.
